Configuration
Projector type
Standard
What's included
VGA cable, power cable, remote control, battery for remote control, carrier bag, lens cap, Quick Start Guide, user manual on CD-ROM

Physical dimensions
Physical dimensions (WxDxH)—mainframe
314.2 x 223.5 x 91.8 mm
Weight—mainframe
Approximately 3.2 kg
Optical and audio systems
Projection system
DLP
Contrast
2,000:1—Native Mode
8,000:1—High Contrast Mode
Aspect ratio
16:10
Brightness
4,100 lumens
Resolution
1,280 x 800 pixels (WXGA)
Light source
High-pressure mercury lamp
Light source life
4,000h/10,000h (Eco)
Lamp wattage
240 W
Lens focal length
f:15.985–21.423 mm
Lens aperture
F:2.51–2.93
Zoom type
Manual
Zoom ratio
1.36x
Focus method
Manual
Projection size
40–300 inches
Projection distance
1.3–7.2 m
Projection ratio
1.113–1.523
Tilt angle
7°—mechanical
Lens shift
Vertical—96.2–112.4%
Keystone correction
Vertical ±30°
Horizontal ±30°
Four corner adjustment
Supported
Input signals
NTSC, PAL, SECAM
3D support
DLP Link
Control system
PJ-Link Class 1, Crestron, AMX Device Discovery, Extron
Speaker
Internal, 10 W, mono
Other supported features
Colour control (Hue, saturation, and gain, Memory, Memory by picture mode, Memory by input), Power on by AC input, Skip input (Auto input search), Digital zoom, Freeze, AV mute, Test pattern
Connectivity
Interfaces - standard
Computer IN
D-SUB 15 pin x 1

Computer OUT
D-SUB 15 pin x 1

Video IN
RCA x 1

S-Video
Mini-Din x 1

Digital terminal
HDMI 1.4 x 1
HDMI 1.4/MHL 2.2 x 1

Audio input terminal
Mini jack 3.5 mm x 2

Audio output terminal
Mini jack 3.5 mm x 1

Control terminal
RS-232C 9-pin x 1
USB micro B—for firmware updates
RJ45 LAN

Security features
Kensington lock
Yes
Password protection of device
Password lock
Other security features
Security lock hole
Supported operating environments
Supported languages
On Screen Display languages
English, Japanese, Simplified Chinese, German, French, Italian, Spanish, Portuguese, Polish, Swedish, Thai, Traditional Chinese, Arabic, Indonesian, Turkish, Norwegian, Danish, Dutch, Korean, Finnish, Czech, Hungarian, Russian

User manual languages
English, Japanese, Simplified Chinese, German, French, Italian, Spanish, Polish, Swedish, Thai, Portuguese, Arabic, Norwegian, Dutch, Danish, Russian

Quick Start Guide languages
English, German, French, Italian, Spanish, Portuguese, Arabic

User manual languages on CD
English, Japanese, Simplified Chinese

Environmental features
Power source
100–240 V, 50/60 Hz
Power consumption
360 W—Maximum consumption mode
300 W—Normal operation mode
240 W—Eco Mode maximum
220 W—Eco Mode standard
Less than 0.5 W—Standby
Less than 2 W—Network standby
Sound power level
34 dB—Standard Mode
36 dB—Standard Mode Maximum
27 dB—Eco Mode
29 dB—Eco Mode Maximum
Environmental standards
RoHS
EU REACH
EU Battery Directive (2006/66/EC)
Packaging and Packaging Waste Directive (94/62/EC)
EU WEEE
ErP (Lot6)
Safety standards
CE Marking
TUV

Electromagnetic Compatibility (EMC) standards
EMC Directive
Australia EMC (C-Tick/RCM)
EN62311 (CE)
Operating environment
Temperature
5–40ºC—0–2,500 ft
5–35ºC—2,500–5,000 ft
5–30ºC—5,000–10,000 ft (High Altitude Mode)

Relative humidity up to 80%
Other environmental features
Eco Mode, Power save on no signal
